YRS3-3M-C Carbon Fiber Multi-Axial Warp Knitting Machine
*This machine is used for producing multi-layer &multi-directional carbon fiber warp knitting fabrics
| Width | 50/100 inches |
| Gauge | E5 E6 |
| Speed | 50-600r/min (The specific speed depend the products.) |
| Weft-insertion Device | Adjustable weft-insertion system between+30°and-30° |
| Pattern Drive | Crankshaft connecting rod system |
| Take-up Device | Electronic Take-up |
| Batching Device | Tension controlled under servo motors |
| Let-off Device | EBA Positive let-off |
| Power | 65kW |
